Rohde & Schwarz FSVA40 аналізатор сигналів та спектру
Rohde & Schwarz FSVA40 Signal and Spectrum Analyzer
Запитати ціну
Rohde & Schwarz FSVA40 signal and spectrum analyzer with 40 GHz frequency range, 160 MHz analysis bandwidth, and low phase noise for RF testing.
Деталі продукту
| Модель | FSVA40 (1321.3008.41) |
| Виробник | Rohde & Schwarz |
| Категорія | Аналізатори спектра |
| Наявність | На замовлення |
Опис
Overview
The Rohde & Schwarz FSVA40 is a versatile signal and spectrum analyzer designed for RF applications from 10 Hz to 40 GHz. With 160 MHz analysis bandwidth and excellent dynamic range, the FSVA40 provides reliable spectral measurements and signal analysis for development, production, installation, and service applications in RF systems.
Key Features
- Frequency range from 10 Hz to 40 GHz
- Signal analysis bandwidth up to 160 MHz
- Optional YIG preselector bypass for 160 MHz analysis across full frequency range
- Low displayed average noise level (DANL) typically –168 dBm (1 Hz) at 1 GHz
- Very low phase noise, typical –118 dBc (1 Hz) at 1 GHz with 10 kHz offset
- High third-order intercept point, typically 20 dBm
- Level measurement uncertainty of 0.4 dB up to 7 GHz
- Touchscreen-based user interface with intuitive operation
Applications
- RF system development and verification
- Production testing of RF components and modules
- Phase noise and spectral purity measurements
- Component characterization and analysis
- Signal analysis and demodulation
Характеристики
| High Frequency (range) | 20GHz <= 50GHz |
| Low Frequency (range) | DC <= 1kHz |
| Form Factor | Benchtop |
