Rohde & Schwarz FSVA3044 аналізатор сигналів та спектру

Overview

The Rohde & Schwarz FSVA3044 is a high-performance signal and spectrum analyzer designed for demanding RF measurements from 2 Hz to 44 GHz. With up to 1 GHz analysis bandwidth and outstanding phase noise performance, the FSVA3044 delivers excellent dynamic range and measurement speed for laboratory research, system verification, and production testing of wireless communications systems.

Key Features

• Frequency range from 2 Hz to 44 GHz, extendable to 54 GHz with options
• Analysis bandwidth up to 1 GHz for simultaneous capture of multiple carriers
• SSB phase noise of –127 dBc/Hz at 10 kHz offset (1 GHz carrier)
• Multi-touch touchscreen display with intuitive interface
• SCPI recorder translates manual operations to automated test scripts
• Event-based actions trigger on rare signal events for debugging
• Digital modulation analysis up to 200 MHz for 5G NR and wireless standards
• High measurement speed for production line applications

Applications

• 5G NR signal analysis and component verification
• Wireless communications R&D and system testing
• Production testing of RF modules and components
• Phase noise and spectral purity measurements
• Complex signal demodulation and analysis
