Rohde & Schwarz SMHU58 High Accuracy Signal Generator
Rohde & Schwarz SMHU58 високоточний генератор сигналів
Запитати ціну
Rohde & Schwarz SMHU58 high-accuracy RF signal generator with 100 kHz to 4.32 GHz range and 0.1 Hz resolution for advanced receiver and LO applications.
Деталі продукту
| Модель | SMHU58 (0835.8011.58) |
| Виробник | Rohde & Schwarz |
| Категорія | RF & Microwave Signal Generators |
| Наявність | На замовлення |
Опис
Огляд
Rohde & Schwarz SMHU58 — високопродуктивний RF генератор сигналів, призначений для вимірювальних застосувань з високими вимогами. При покритті частот до 4,32 ГГц та виключною спектральною чистотою, SMHU58 ідеально підходить для тестування приймачів, застосувань локального генератора та систем вимірювання шуму, де критична цілісність сигналу.
Основні характеристики
- Діапазон частот: 100 кГц–4320 МГц з роздільною здатністю 0,1 Гц
- Час встановлення частоти: менше 10 мс
- Режим швидкого сканування: до 200 заданих користувачем частот менш ніж за 1 мс на установлення
- Виключна спектральна чистота для вимірювань сусідніх каналів та зовнішніх каналів
- FM модуляція: постійний струм до 1 МГц із мінімальним зміщенням частоти у режимі FM DC
- AM модуляція: постійний струм до повного діапазону частот модуляції із рівномірною частотною характеристикою для тестування приймачів VOR/ILS
- Імпульсна модуляція: час нарастання/спаду 20 нс (типово <10 нс для частот >200 МГц) із коефіцієнтом ввімкнення/вимкнення 80 дБ
- Зміщення фази: регульоване в кроках 1°
Застосування
- Тестування селективності та чутливості приймачів
- Застосування низькошумового локального генератора
- Опорний сигнал для систем вимірювання шуму
- Тестування систем телеметрії та супутникових комунікацій
- Тестування радарних і мікрохвильових систем каналів зв'язку
Характеристики
| Frequency | The frequency can be set with a resolution of 0.1 Hz over the entire range, and this is sufficient even for measurements on extremely narrowband DUTs. Both instruments supply frequencies down to 1 kHz. The frequency setting time is below 10 ms. In the fast mode up to 200 user-defined frequencies can be handled by means of a trigger signal or by memory sweep in less than 1 ms per setting. |
| Spectral Purity | R&S®SMGU/SMHU fulfill requirements for selectivity measurements on top-class receivers. Signals of extremely high spectral purity afford critical adjacent-channel, in-channel and out-of-channel measurements with a wide tolerance margin. Phase noise remains low right up to the carrier. R&S®SMGU/SMHU are therefore ideal for LO applications or as a low-noise reference in noise measurement systems. |
| Frequency Modulation | The FM modulation frequency range extends from DC to 1 MHz. In FM DC mode a high carrier-frequency accuracy is attained. The frequency offset occurring with FM DC selected is extremely small. |
| Amplitude Modulation | The whole of the modulation frequency range can be used down to carrier frequencies of less than 100 kHz. The minimal phase shift at 30 Hz (AM DC) and a flat frequency response make for the precision amplitude modulation that is required for testing VOR/ILS navigation receivers. |
| Pulse Modulation | Rise/fall times of 20 ns (typ. <10 ns for frequencies >200 MHz) and an on/off ratio of 80 dB open up a wide range of possibilities for testing telemetry, microwave link, radar and satellite communications systems. |
| Digital and Analog Sweep | In addition to the digital, step-by-step sweep with presettable start and stop frequency, span, step width and step time, an analog frequency and level sweep is also provided. |
| Phase Offset | The phase of the RF output signal can be varied in steps of 1 using keyboard entry or the spinwheel. This makes it easier to adjust for phase quadrature during noise measurements and to investigate phase-critical components. |
