TDK-Lambda Z160-1.3-LAN-U джерело живлення постійного струму
TDK-Lambda Z160-1.3-LAN-U DC Power Supply
Запитати ціну
TDK-Lambda Z160-1.3-LAN-U is a programmable DC power supply with 160V output, 1.3A capacity (208W), and optional LAN interface for networked remote control.
Деталі продукту
| Модель | Z160-1.3-LAN-U |
| Виробник | TDK-Lambda |
| Категорія | Одноканальні джерела живлення постійного струму |
| Наявність | На замовлення |
Опис
Overview
The TDK-Lambda Z160-1.3-LAN-U is a versatile programmable DC power supply for laboratory, test, and industrial applications. Featuring 160V output at 1.3A (208W) with optional LAN connectivity, it enables networked control and monitoring across distributed test environments. The unit includes built-in USB, RS-232, and RS-485 interfaces for maximum connectivity flexibility.
Key Features
- 160V / 1.3A / 208W output power
- Optional LAN interface for networked operation
- Built-in USB, RS-232, and RS-485 interfaces
- Constant current or voltage operation modes
- User-programmable output signal pins
- Selectable 115-230VAC input (85-265VAC range)
- Active power factor correction (0.99 typical)
- 2U height, rack or bench mountable
- Front panel control and status display
- 5-year warranty, UL/CE listed
Applications
- Networked test system architectures
- Laboratory and bench-top testing
- Multi-location automated testing
- Industrial process monitoring and control
Характеристики
| Voltage Range Selector | 100-199 |
| Output Voltage | 160 V |
| Current Range Selector | 0-2.49 |
| Output Current | 1.3 A |
| Power Range Selector | 200-499 |
| Power Rating | 208 W |
| Mounting Type | Bench Top |
| Input Voltage | 85-265 VAC |
| Series | Z+ Series |
| Display | Digital |
| Interface | USB,LAN,RS-232,RS-485 |
| Number of Outputs | Single Output |
| Programmable | Yes |
| Rack Space | 2U |
| Special Features | Constant Current, Constant Voltage, Master/Slave Modes |
