EA Elektro-Automatik EA-PSI 9360-10 DT джерело живлення постійного струму
EA Elektro-Automatik EA-PSI 9360-10 DT DC Power Supply
EA Elektro-Automatik EA-PSI 9360-10 DT high-voltage benchtop DC power supply with 360V/10A/1000W output, autoranging capability, integrated waveform generator, and comprehensive protections.
Деталі продукту
| Модель | EA-PSI 9360-10 DT |
| Виробник | EA Elektro-Automatik |
| Категорія | Одноканальні джерела живлення постійного струму |
| Наявність | На замовлення |
Опис
Overview
The EA Elektro-Automatik EA-PSI 9360-10 DT is a microprocessor-controlled high-voltage benchtop DC power supply designed for specialized laboratory and industrial applications requiring extended voltage ranges. Delivering 360V at 10A with a maximum output of 1000W, this unit features an intelligent autoranging output stage that flexibly allocates voltage and current within power limits. The supply operates from universal AC input (90–264V) with active Power Factor Correction, achieving up to 92% efficiency globally.
The interactive color TFT touch display provides continuous monitoring of output voltage, current, and power. Sophisticated protection systems—including overvoltage (OVP), overcurrent (OCP), overpower (OPP), and overtemperature (OT) protection—ensure safe operation of high-voltage equipment. An integrated discharge circuit safely reduces output voltage below 60V DC after shutdown. The galvanically-isolated analog interface, USB, and Ethernet connectivity enable integration into advanced automated measurement and control systems.
Key Features
- Autoranging output stage (0–360V, 0–10A, up to 1000W) with variable maximum power limit
- Active Power Factor Correction (PFC) for universal AC input (90–264V)
- High efficiency up to 92% with integrated output filter for ripple suppression
- Built-in function generator supporting arbitrary waveforms and 99 programmable sequences
- Multi-layer protection: OVP, OCP, OPP, and overtemperature monitoring with automatic shutdown
- Galvanically-isolated analog interface with 0–10V or 0–5V control/feedback signals
- Responsive color touch panel with multi-language interface (English, Russian, Chinese, German)
- Discharge circuit ensures rapid safe voltage reduction to below 60V DC
- USB port for function/sequence management and firmware upgrades
- SCPI command protocol and ModBus RTU support for remote automation
- Included Windows PC control software with single and multi-device operation modes
Applications
- High-voltage laboratory testing and equipment characterization
- Specialized power electronics design and development
- Industrial equipment validation and commissioning
- Automated test systems for high-voltage components
- Research and development in power conversion systems
Included Accessories
- 2-meter mains cord with Schuko/UK plug
- 1.8-meter USB connection cable
- USB storage device with control software and technical documentation
Характеристики
| Voltage Range Selector | 300-499 |
| Output Voltage | 360 V |
| Current Range Selector | 10-19.9 |
| Output Current | 10 A |
| Power Range Selector | 1,000-2,499 |
| Power Rating | 1 kW |
| Mounting Type | Bench Top |
| Input Voltage | 100-240 VAC |
| Series | EA-PSI 9000 DT Series |
| Dimensions | 12.12 x 7.67 x 17.75" |
| Interface | 1x USB-B for communication, 1x USB-A for functions, 1x LAN for communication, 15 pole D-Sub (female) |
| Number of Outputs | Single Output |
| Operating Temperature Range | 32-122°F |
| Relative Humidity Range | ≤80% |
| Resistance Range | 0.8-1080 Ω |
| Safety | EN 60950, EN 61326, EN 61010, EN 55022 Class B |
| Special Features | Autoranging |
