Rohde & Schwarz HMC8042 джерело постійного струму

Overview

The Rohde & Schwarz HMC8042 is a dual-channel DC power supply offering independent control of two isolated outputs. With a maximum total power of 100W (50W per channel) and a voltage range of 0V to 32V with up to 5A per channel, it is ideal for hardware developers and laboratory applications requiring flexible multi-output power delivery.

Key Features

• Dual output channels: 0–32V, 0–5A per channel (50W max. each, 100W total)
• Resolution: 1 mV / 0.1 mA
• Galvanically isolated, floating, and short-circuit proof outputs
• Independent protective functions for each channel
• Clear QVGA display of voltage, current, and power
• Outputs can be connected in series or parallel for higher voltage or current
• High energy efficiency with minimal heat dissipation at full load
• Data logging to USB flash drive in CSV format
• Electronic fuses individually programmable per channel
• EasyArb and EasyRamp functions for sequenced channel control
• LXI-compliant with LAN and USB interfaces standard
• GPIB available on HMC8042-G version
• Half-rack width, suitable for 19-inch rack installation

Applications

• Multi-rail power supply development
• Laboratory testing of dual-supply circuits
• Industrial prototyping environments
• Component testing with independent supply control
